High Brightness LCD Panel

Deliver Clearly Sunlight Readable Screen Outdoors,

Even In Direct Sunlight

Home
>>
PRODUCT
>>
LCD MODULE
>>
HIGH BRIGHTNESS LCD PANEL

HIGH BRIGHTNESS LCD PANEL

• FHD / UHD IPS LCD Panel
• 700Nit / 1000Nits High Brightness
• E-LED Backlight With LED Driver Board
• Standard 400x400 VESA Mounting Hole
• Lifetime ≥ 30,000 Hrs
• 24/7
• Landscape&Portrait Installation
• Ideal for Semi-Outdoor Application

Size

Brightness

  • 700cd/m²
  • 1000cd/m²
  • 1500cd/m²
INQUIRY TO BUY
Download Information
HIGH BRIGHTNESS LCD PANEL

Product Feature

HB-E Series

Find the Screen That's Right for Your Business.



Not sure which LCD screen best suits your area or your business? Our expert customer service representatives are ready to answer any of your questions. If you require more technical information about a particular product or want to know which is right for your business, call us at +86 181 5279 4213. You also can live chat with one of our representatives at any time. Moreover, we offer secure checkout 24-hours a day, 7 days a week.

Specs

  • Panel

    Diagonal Size
    32Inch
    Luminance
    700 cd/m²
    Luminance (Optional)
    1,000 cd/m² ~ 1,500 cd/m²
    Resolution
    1920(3)×1080, FHD 40PPI
    Active Area
    698.4(W)×392.85(H) mm
    Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
    Landscape/Portrait
    Yes/Yes
    Good View at
    Symmetry
    Color Depth
    16.7M 70% NTSC
    Refresh Rate
    60Hz
    Signal Type
    LVDS (2 ch, 8-bit) , 51 pins Connector
    Panel Type
    a-Si TFT-LCD, LCM
    Pixel Format
    RGBW Vertical Stripe
    Treatment
    Hard coating (2H), Reflection 1.5% (Typ.)
    Contrast Ratio
    1000 : 1 (Typ.) (TM)
    Work Mode
    S-IPS, Normally Black, Transmissive
    Response
    6 (Typ.)(G to G) ms
    Aspect Ratio
    16:9 (H:V)
    Orientation
    Landscape / Portrait
    Auto Brightness Mode
    Yes
    Adj Brightness Mode
    Yes, Optional
    PWM Brightness Mode
    Yes, Optional
    Operation Time
    24/7

  • Backlight Details

    Lifetime
    30K Hrs
    Lamp Type
    WLED
    With LED Driver
    Yes
    Edge LED
    Yes

  • Environment

    Operating Temp.
    0 ~ 50 °C
    Storage Temp.
    -20 ~ 60 °C

  • Warranty & Others

    Warranty
    24 Months
    Acessories (Optional)
    LVDS Cable, Backlight Cable
    Ambient Light Sensor
    Yes

  • LED Driver

    Input Voltage
    24.0±1.2V
