High Brightness Open Frame LCD

Open Kit Design for Enclosure Customization

Home
>>
PRODUCT
>>
OPEN FRAME LCD
>>
HIGH BRIGHTNESS OPEN FRAME LCD

HIGH BRIGHTNESS OPEN FRAME LCD

• Open Kit Design for Enclosure Customization
• Sunlight Readable High Brightness
• Blackening Effect Free (High Tni 110° C)
• Multiple External Input Interfaces
• Brightness Auto Adjustment with Ambient Light Sensor

Size

Brightness

  • 1500cd/m²
  • 2000cd/m²
  • 2500cd/m²
  • 3000cd/m²
  • 3500cd/m²
  • 4000cd/m²
  • 5000cd/m²
INQUIRY TO BUY
Download Information
HIGH BRIGHTNESS OPEN FRAME LCD

Product Feature

Our Hibright open frame display is built to stand out in different outdoor environments with 2,500 nits (or higher) ultra-high brightness. The LED-backlit open frame panels include brightness levels that maximise visibility, along with features such as an energy-saving Auto Brightness Sensor and Anti-Burn-in technology that make the ultra-high brightness digital signage display ideal for 24/7 outdoor use. An open-frame option boosts adaptability, as it allows for easier integration into customised designs. In contrast, We also can customized  dual-fan cooling bar design coupled with a HeatControl sensor keeps temperatures in control, further enhancing the KT display’s aptitude for outdoor use.





2500 NITS ULTRA-HIGH BRIGHTNESS

With 2500 nits ultra-high brightness, the HIBRIGHT open frame displays provide optimal readability, whether in direct or indirect sunlight conditions, while retaining the superior image quality Hibright-LCD large format displays are known for.

The PO-Series open frame display features 2500 nits high brightness

24/7 OPERATION UNDER SUNLIGHT

Glad to made of a Public Information Display (PID) panel for 24/7 operation, in which the liquid crystal cell can resist heat up to 110°C / 230°F, compared to the typical TV panel, around 65-75°C (149-167°F). This unique high-temperature liquid crystal technology prevents the black spots that can develop on competing displays when subject to high heat loads from direct sunlight.

The open frame display adopt PID panel for 24/7 use

LOW REFLECTION FOR SUPERIOR READABILITY

Our Hibright open frame displays adopt the Quarter Wave Plate (QWP) polariser with a low reflection solution (Reflectance ≤ 1.45%) to enhance the visibility and colour vibrancy of the display for outdoor applications.

BUILT-IN ECOSMART SENSOR

An embedded energy-saving EcoSmart Sensor, exclusively designed by HIBRIGHT LCD, can automatically adjust display backlight brightness based on the ambient luminance, particularly in outdoor settings, which can significantly save energy.

The PO-Series open frame displays has a built-in EcoSmart Sensor

Specs

  • Panel

    Model No.
    HBKT320D25I01
    Diagonal Size
    32Inch
    Luminance
    2500 cd/m² Typ.
    Luminance (Optional)
    1500 cd/m² ~ 5000 cd/m²
    Blackening Effect Free
    High Tni 110°C
    Resolution
    1920(3)×1080, FHD 40PPI
    Active Area
    698.4(W)×392.85(H) mm
    Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
    Landscape/Portrait
    Yes/Yes
    Good View at
    Symmetry
    Color Depth
    16.7M 70% NTSC
    Refresh Rate
    60Hz
    Signal Type
    LVDS (2 ch, 8-bit) , 51 pins Connector
    Panel Type
    a-Si TFT-LCD, LCM
    Pixel Format
    RGBW Vertical Stripe
    Treatment
    Hard coating (2H), Reflection 1.5% (Typ.)
    Contrast Ratio
    1000 : 1 (Typ.) (TM)
    Work Mode
    S-IPS, Normally Black, Transmissive
    Response
    6 (Typ.)(G to G) ms
    Aspect Ratio
    16:9 (H:V)
    Orientation
    Landscape / Portrait
    Auto Brightness Mode
    Yes
    Adj Brightness Mode
    Yes, Optional
    PWM Brightness Mode
    Yes, Optional
    Operation Time
    24/7

  • Connectivity

    RS232 Input
    Yes, (Optional)
    Video Input
    HDMI x1, VGA x1, DVI x1, USB x1
    Audio Input
    Yes

  • Physical Dimension

    Monitor Dimension
    731 x 430.55 x 70.5mm
    Monitor VESA Mounting
    230 x 380 mm 4-M6
    Monitor Weight
    8.5kgs
    Bezel Color
    Black
    Bezel Width
    14.8/14.8/14.8/19.8mm
    Package Type
    12pcs/plt
    Package Dimension
    82 x 70 x 62cm
    Package Weight
    65kgs

  • Backlight Details

    Lamp Type
    WLED
    Direct LED
    Yes
    Life time
    60K hours
    With LED Driver
    Yes

  • Power

    Power Supply
    Built-In Power
    Power Type
    AC 100-240V, 50/60Hz
    Power Consumption
    120W

  • Sensor

    Ambient Light Sensor
    Yes
    Temperature Sensor
    Yes (Optional)

  • Environment

    Operating Temp.
    0 ~ 50 °C
    Storage Temp.
    -20 ~ 60 °C

  • Warranty & Others

    Assessories
    1.5m power cord, remote control
    Fan Cooler Bar
    2pcs (Optional)
    Warranty
    24 Months
